    YZF-R3

    This lightweight supersport with it's MotoGP-inspired look makes it the most radical 300 on the street... or track. Its sleek bodywork echoes the YZR-M1 race bike – and the aggressive dual LED headlights underline its pure R-series DNA.

    High-specification 37mm inverted front forks offer enhanced suspension feel and feedback – while a low fuel tank and revised handlebar position improve rider ergonomics to give you greater comfort and control.

    Step up to the plate and enter R-World.

    Features

    321cc Inline Twin Cylinder Engine

    Featuring the latest combustion technology together with lightweight forged aluminium pistons and all-aluminium DiASil cylinders with an offset design, the smooth-running and quick-revving YZF-R3 engine produces easy-to-manage power.

    Inverted Front Forks

    Achieving the right balance of comfort and sport riding performance for both street and track, the new KYB 37mm inverted fork features a larger surface area between the outer and inner tubes than on conventional forks. The inverted design significantly improves fork-leg rigidity, giving a sporty front-end feel and precise levels of surface feedback - while maintaining high levels of riding comfort.

    10-Spoke Cast Wheels wtih ABS

    Ten-spoke cast aluminium wheels, single 298mm front brake disc with a floating twin-piston caliper, 32 degrees of handlebar steering range, a 780mm seat height and approximately 50/50 front-rear weight ensures the YZF-R3 chassis delivers agile and responsive handling. For added control, Anti-Lock Braking is fitted as standard equipment raising confidence levels even further.

    Lightweight Chassis

    A lightweight high tensile steel tubular frame with a simple design incorporates the engine's crankcase as a stressed structural member of the chassis. The long asymmetrical swingarm design ensures the efficient transmission of engine power to the rear wheel and delivers excellent straight-line stability.

    Distinctive R-Series Styling

    The YZF-R3 features a front fairing and windscreen design that pays homage to Yamaha's flagship MotoGP race bike, the YZR-M1. The aggressive new look also achieves outstanding aerodynamic performance providing an increase of up to 8km/h in top speed. The YZR-M1 style central fairing duct also functions to direct airflow to the radiator, contributing to engine cooling performance.

    Information Rich Instrument Panel

    A trick multi-function instrument panel includes an analogue tachometer and digital speedometer – and to underline its strong R-series heritage the R3’s instruments feature a shift timing indicator lamp similar to the design used on the YZF-R1. There’s also a gear position indicator, fuel gauge, water temperature gauge as well as fuel economy information, clock, trip-meters and more. All of course wrapped into an impressive liquid-crystal-type display.

    Technical Specification

    • Engine Type Liquid cooled, 4-stroke, DOHC, 4-valve
    • Displacement (cc) 321.0
    • Bore x Stroke (mm) 68.0 × 44.1
    • Compression Ratio 11.2 : 1
    • Lubrication System Wet sump
    • Fuel Management Fuel Injection
    • Ignition TCI
    • Starter System Electric
    • Fuel Tank Capacity (L) 14.0
    • Final Transmission Chain
    • Transmission Constant mesh 6-speed
    • Frame Type Diamond
    • Suspension Front USD Telescopic forks, 130mm travel
    • Suspension Rear Swingarm, 125mm travel
    • Brakes Front Hydraulic single disc, 298mm - ABS
    • Brakes Rear Hydraulic single disc, 220mm - ABS
    • Tyres Front 110/70-17M/C 54H Tubeless
    • Tyres Rear 140/70-17M/C 66H Tubeless
    • Length (mm) 2090
    • Width (mm) 730
    • Height (mm) 1140
    • Seat Height (mm) 780
    • Wheelbase (mm) 1380
    • Ground Clearance (mm) 160
    • Wet Weight (kg) 167
    • Colours
